Bently Nevada 3300 NSv Proximity Probe – 330903-00-03-10-12-00
Description
New & original 3300 NSv proximity probe for industrial machinery monitoring. Features enhanced chemical resistance and superior side-view characteristics vs. legacy probes. Ideal for compressors, turbines, and rotating equipment. Shipped in factory packing with 12-month warranty.
Technical Specifications
| Brand | Bently Nevada |
| Full Part Number | 330903-00-03-10-12-00 |
| Suffix Breakdown | -00- = 0mm unthreaded length -03- = 30mm case length -10- = 1.0m cable -12- = ClickLoc/FluidLoc -00- = No agency approval |
| Measurement Range | 0.25-1.75mm (10-70 mils) |
| Accuracy (DSL) | ±0.06mm (±2.3 mils) |
| Output Signal | -1 to -13 Vdc linear range |
| Temp Range | -52°C to +177°C (-62°F to +351°F) |
| Probe Resistance | 4.2Ω ±0.5Ω |
Installation Guide
- Recommended gap: 1.0mm (40 mils)
- Max torque: 0.56 N•m (5 in•lb)
- Min target diameter: 13mm (0.5 in)
- Min bend radius: 25.4mm (1.0 in)
Compatibility
Electrically and mechanically compatible with Bently Nevada’s 3300 RAM probes and extension cables. Not compatible with 190-series probes.
Certifications
Agency approval option: 00 (Not Required)
Package & Warranty
- Factory-sealed packaging
- 12-month warranty
- Shipping: FedEx/UPS/DHL (global)
Alternative Models Comparison
| Model | Cable Length | Case Length | Details |
|---|---|---|---|
| 330903-00-03-10-12-00 | 1.0m | 30mm | Current model |
| 330903-00-05-05-12-00 | 0.5m | 50mm | Shorter cable |
| 330903-00-04-05-01-00 | 0.5m | 40mm | Different connector |
FAQ
Q: Is this compatible with 3300 XL systems?
A: Yes, works with all 3300 XL NSv Proximitors.
Q: Maximum wiring distance?
A: 305m (1000 ft) between probe and monitor.
Q: Pressure rating?
A: Contact Bently Nevada for pressure testing.
