Bently Nevada 3300 NSv Probe: Advanced Machinery Monitoring
Essential Specifications
- Part Number: 330903-00-03-50-02-05
- Measuring Range: 1.5mm (60 mils)
- Scale Factor: 7.87 V/mm ±12.5%
- Accuracy: ±0.06mm deviation
- Temp Range: -52°C to +177°C
- Cable Length: 5.0 meters
Probe Construction
- Thread Type: M8X1 without armor
- Case Length: 30 mm
- Tip Material: PPS plastic
- Case Material: 304 stainless steel
- Seal: Viton O-ring
Performance Features
- Superior chemical resistance vs older models
- Enhanced side-view characteristics
- 0-10 kHz frequency response
- 75Ω coaxial cable with FEP insulation
- Miniature ClickLoc connector
Installation Guide
- Optimal Gap: 1.0 mm from target
- Max Torque: 0.56 N•m (finger tight)
- Bend Radius: >25.4 mm
- Wiring: Shielded triad cable (max 305m)
- Thread Engagement: 12 mm minimum
Package & Support
- 12-month factory warranty
- New in original packaging
- Global shipping: FedEx, UPS, DHL
- Multiple agency approvals (option 05)
Technical Questions
Q: Minimum target size?
A: 8.9mm diameter (13mm recommended)
Q: Cable options?
A: Available in 0.5m, 1m, 5m, 7m lengths
Q: Pressure rating?
A: Viton sealed (custom testing available)
