Description
Bently Nevada 330903-00-04-05-01-00: Compact NSv Vibration Probe
M8X1 threaded proximity sensor with 40mm case length. New original unit with chemical-resistant PPS tip and 12-month warranty.
PRODUCT CONFIGURATION
- Base Model → 330903: NSv Probe, M8X1 thread, no armor
- Unthreaded Length → -00-: 00 mm
- Case Length → -04-: 40 mm compact design
- Cable Length → -05: 0.5 meter (20 in)
- Connector Type → -01: ClickLoc coaxial with protector
- Certification → -00: No agency approvals
TECHNICAL PERFORMANCE
- Electrical Specifications
- Probe Resistance: 4.0Ω ±0.5Ω @0.5m
- Cable Capacitance: 21.3 pF/ft (69.9 pF/m)
- Frequency Range: DC to 10kHz (±3dB)
- Signal Rolloff: <0.5dB @5kHz with 1000ft wiring
- Mechanical Specifications
- Thread Engagement: 12mm max for M8X1
- Bend Radius: 25.4mm (1.0in) minimum
- Installation Torque: Finger tight to 0.56 N•m (5 in•lb)
- Case Torque: 5.1 N•m recommended (7.3 N•m max)
- Measurement Capabilities
- Target Size: Min 8.9mm Ø (13mm recommended)
- Scale Factor Deviation: < ±0.06mm (±2.3 mils)
- Output Linearity: ±1% over full range
- Temperature Drift: <0.05%/°C
INSTALLATION GUIDE
- Mounting: M8X1 threaded installation
- Gap Setting: Optimal at 1.0mm (40 mils) from target
- Wiring: Shielded triad cable, max 305m (1000ft)
- Connection: Miniature coaxial ClickLoc connector
- Pressure Warning: Viton O-ring seal (not pressure tested)
PACKAGE CONTENTS
- 330903-00-04-05-01-00 probe assembly
- ClickLoc connector protector
- Manufacturer datasheet
SUPPORT & SHIPPING
- Warranty: 12-month manufacturer coverage
- Delivery: FedEx, UPS, DHL with tracking
- Availability: In stock for same-day dispatch
EXPERT FAQ
Q: What’s the advantage of 40mm case length?
A: Fits space-limited installations where standard probes won’t fit.
Q: Can I use this in high-temperature environments?
A: Yes, rated for continuous operation at +177°C (+351°F).
Q: Is the cable replaceable if damaged?
A: No, cable is permanently attached – consider armored versions for harsh environments.
Q: How does temperature affect accuracy?
A: Less than 0.05% deviation per °C across full operating range.
