Bently Nevada 3300 NSv Proximity Probe: Advanced Machinery Monitoring
Product Overview
New factory-sealed 330903-00-04-05-02-05 proximity probe with M8X1 threading. Features 40mm case length and enhanced chemical resistance. 12-month warranty included.
Complete Model Suffix Details
- 330903: Base model
- -00: 00 mm unthreaded length
- -04: 40 mm overall case length
- -05: 0.5 meter cable
- -02: ClickLoc connector, standard cable
- -05: Multiple agency approvals
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 NSv Proximity Probe
- Electrical: 4.0Ω ±0.5Ω probe resistance
- Cable Data:
- Center conductor: 0.220 Ω/m
- Shield resistance: 0.066 Ω/m
- Capacitance: 69.9 pF/m
- Performance:
- Frequency response: 0-10 kHz (±3dB)
- Deviation: < ±0.06 mm
- Scale factor: 7.87 V/mm (±12.5%)
- Environmental:
- Operating temp: -52°C to +177°C
- Storage temp: -62°F to +351°F
- Mechanical:
- Case material: AISI 304 SST
- Tip material: PPS plastic
- Min bend radius: 25.4 mm
- Max torque: 0.56 N•m
Installation Guide
- Optimal gap: 1.0 mm (40 mils)
- Target size: Min Ø8.9mm, recommended Ø13mm
- Thread engagement: Max 12 mm for M8x1
- Field wiring: 305m max with shielded triad cable
Industry Compliance
Multiple international certifications (-05 suffix) ensure global acceptance.
Package Contents
- 3300 NSv Probe with 0.5m cable
- Factory packaging with protective caps
- 12-month manufacturer warranty card
Shipping Options
FedEx | UPS | DHL – Express global delivery available
Frequently Asked Questions
Q: What’s the cable capacitance specification?
A: 69.9 pF per meter (21.3 pF/ft) typical
Q: Can I use this in high-pressure environments?
A: Features Viton O-ring seal – contact for custom pressure testing
Q: Minimum shaft size for accurate measurement?
A: 8.9mm minimum, 13mm recommended for consistent results
Q: What’s the shield resistance specification?
A: 0.066 Ω/m (0.020 Ω/ft) for electromagnetic protection
