Description
Bently Nevada 3300 NSv Proximity Probe with Country-Specific Certification
Product Highlights
New 330903-00-04-05-02-CN proximity probe with 40mm case length and country-specific approvals. Features M8X1 threading and standard cable. Direct RAM probe replacement with enhanced chemical resistance. Includes 12-month factory warranty.
Complete Suffix Breakdown
- ▸ 330903: NSv Probe Base Model
- ▸ -00-: Unthreaded Length (0 mm)
- ▸ -04-: 40 mm Case Length
- ▸ -05-: 0.5 m Cable Length
- ▸ -02-: Mini ClickLoc Connector
- ▸ -CN: Country-Specific Certification
Detailed Specifications
- Resistance Stability: 4.0Ω ±0.5Ω @20°C
- Cable Shielding: 0.066 Ω/m shield resistance
- Vibration Measurement: ±0.06mm linearity error
- Response Time: <10 μs signal latency
- Sealing Material: Viton O-ring (chemical resistant)
- Thread Engagement: 12mm max (M8x1)
Comparison Guide
Current Model: 330903-00-04-05-02-CN
– Case Length: 40mm
– Cable: Standard
– Approvals: Country-Specific (CN)
Comparison Model A: 330903-00-05-05-01-00
– Case Length: 50mm
– Cable: FluidLoc
– Approvals: Standard
Comparison Model B: 330903-00-05-05-11-00
– Case Length: 50mm
– Connector: With protector
– Approvals: Standard
Certification & Compliance
Meets country-specific safety standards (CN suffix). Complies with IEC 60079 for hazardous environments. Documentation included.
Installation Notes
- Optimal sensing distance: 1.0mm from target
- Max cable bend: 25.4mm radius
- Mounting torque: 5.1 N•m (45 in-lb)
- Use with shielded triad cable (max 305m)
FAQ
Q: What countries recognize CN certification?
A: China, Vietnam, Thailand – contact for specific compliance documents
Q: Difference between standard and FluidLoc cable?
A: FluidLoc has superior fluid resistance for chemical environments
Q: Can 40mm case replace 50mm units?
A: Only where mounting depth allows – verify clearance first
Q: Lead time for customs documentation?
A: CN-certified units ship with pre-filled customs forms
