Description
330903-00-04-05-12-00: Compact Vibration Probe with FluidLock
Bently Nevada’s 40mm-shortcase probe features FluidLoc cable technology for tight spaces. Ideal for pumps, gearboxes, and compact machinery with ±0.06mm precision.
Part Number Decoder
- Core: 330903 (NSv Probe, M8X1)
- Level 1: -00- → Zero unthreaded length
- Level 2: -04- → 40mm compact case
- Level 3: 05 → 0.5m cable length
- Level 4: 12 →
- ClickLoc connector
- FluidLoc sealed cable
- Level 5: -00 → Standard certification
Space-Saving Advantages
- Case Length: 40mm (20% shorter than standard)
- Clearance Needed: 45mm behind mounting surface
- Weight: 85g (lightest in NSv series)
- Profile: 8mm diameter tip
FluidLoc Cable Performance
- Ingress Protection: IP68 when submerged
- Pressure Rating: 15 bar static / 5 bar dynamic
- Chemical Resistance:
- Resists glycol-based fluids
- Compatible with synthetic lubricants
- Cable Flexibility: 50% higher bend cycles than standard
Installation Guide
- Mounting Depth: 12mm max thread engagement
- Clearance Check: Verify 360° radial access
- Gap Verification: Use 1.0mm feeler gauge
- Cable Routing: Maintain 25.4mm bend radius
Package Contents
- 1x 330903-00-04-05-12-00 probe
- Installation torque guide
- Chemical compatibility chart
- ESD-safe packaging
Global Shipping
- Carriers: FedEx | UPS | DHL
- Express Option: Next-day air available
- 12-month seal integrity warranty
Technical FAQ
Q: Difference between -04- and -05- case?
A: -04- is 40mm length vs standard 50mm – saves space in tight installations.
Q: FluidLoc vs armored cable?
A> FluidLoc provides fluid resistance without metal armor – reduces weight by 40%.
Q: Minimum clearance behind mount?
A> 45mm required for connector clearance.
Q: Compatible with hazardous areas?
A> Standard version only – contact for ATEX/IECEx options.
Q: Vibration limits for compact installs?
A> 15g RMS maximum in confined spaces.
