Description
Bently Nevada FluidLoc Proximity Probe: Reliable Sensing in Wet Environments
OEM 330903-00-04-10-11-00 with specialized FluidLoc cable technology. Features extended 40mm case and M8x1 threading for versatile installations.
Configuration Details
Part Number Breakdown:
- 330903: Base Model
- 00: 0mm Unthreaded Section
- 04: 40mm Case Length
- 10: 1.0 Meter Cable
- 11: FluidLoc Cable with Protected ClickLoc
- 00: No Agency Approvals
Technical Specifications
| Electrical Performance | Mechanical Properties |
| Probe Resistance: 4.2Ω ±0.5 | Thread Size: M8x1 |
| Scale Factor: 7.87 V/mm | Case Length: 40mm |
| Frequency Response: 0-10 kHz | Max Torque: 0.56 N•m |
| Cable Type: FluidLoc FEP | Thread Engagement: 12mm max |
Performance Characteristics
- Linear Detection Range: 1.5mm (0.25mm to 1.75mm)
- Optimal Gap Setting: 1.0mm from target surface
- Measurement Linearity: ±0.06mm deviation
- Minimum Target Size: 8.9mm diameter
- Recommended Target: 13mm diameter
Industrial Applications
- Coolant-flooded machining centers
- Food processing washdown areas
- Marine engine monitoring
- Hydraulic power units
- Chemical processing pumps
Compatibility Information
Direct replacement for 3300 RAM probe systems. Compatible with Bently Nevada 3300 XL NSv Proximitor monitors using 75Ω coaxial connections.
Package Contents
- 1 x 3300 NSv proximity probe
- 1 x ClickLoc connector with protector
- Installation documentation
- 12-month manufacturer warranty
Global Shipping
Available via FedEx, UPS, and DHL with full tracking. International shipping options.
Technical Questions
Q: What makes FluidLoc cable different?
A: Specialized construction resists fluid penetration and maintains performance in wet conditions
Q: Maximum wiring distance to monitor?
A: 305 meters with shielded triad cable
Q: Compatible with high-pressure washdowns?
A: Yes, FluidLoc provides superior protection in washdown environments
Q: Minimum bend radius for cable?
A: 25.4mm during installation and operation
Q: Temperature limits during operation?
A: -52°C to +177°C continuous operation
Q: Difference between 40mm and 20mm case?
A: Longer case provides more mounting flexibility in deep cavities
