Description
Fluid-Resistant Sensor with Special Cable Protection
Main Features
- FluidLoc cable resists oils and chemicals
- Medium 40mm case length
- M8X1 metric thread
- Worldwide safety certifications
Part Number Explained
- 330903: Base model
- M8 thread without armor
- 00: 0mm unthreaded section
- 04: 40mm case length
- 10: 1m cable length
- 11: ClickLoc + FluidLoc cable
- 05: Multiple approvals
Measurement Performance
- Response Speed: 0-10,000 Hz
- Target Size: Min 8.9mm diameter
- Accuracy Error: Less than ±0.06mm
- Voltage Output: -1V to -13V DC
Cable Specifications
- Type: FluidLoc (fluid-resistant)
- Center Wire: 0.220 Ω/m
- Shield: 0.066 Ω/m
- Capacitance: 69.9 pF/m
- Max Distance: 305 meters
Physical Limits
- Bend Radius: 25.4mm minimum
- Thread Depth: 12mm maximum
- Install Torque: Finger tight + max 0.56 N•m
- Temp Limits: -52°C to +177°C
Support & Delivery
- Condition: New in original package
- Warranty: 12 months
- Carriers: FedEx, UPS, DHL
- Global: Ships internationally
Important Questions
Q: What is FluidLoc cable?
A: Special protection against oils and chemicals.
Q: How long is the cable?
A: 1 meter with extension capability.
Q: What approvals does it have?
A: Certified for global hazardous locations.
Q: Why 40mm case length?
A: Balanced size for most industrial uses.
