Description
Bently Nevada 3300 NSv M8X1 Proximity Probe with 5m Cable
Brand new industrial vibration sensor. M8X1 thread, 40mm case length, standard cable. 12-month warranty included.
330903-00-04-50-02-00 Identification
Complete suffix breakdown:
- 330903: Base model
- -00-: 00 mm unthreaded length
- -04-: 40 mm case length
- -50-: 5.0 meter cable
- -02-: ClickLoc connector
- -00: No agency approvals
Key Specifications
| Electrical Resistance | 5.3 ± 0.7 ohms |
| Frequency Response | 0-10,000 Hz |
| Voltage Output | -1 to -13 Vdc |
| Cable Capacitance | 69.9 pF/m |
| Min. Target Size | 8.9 mm diameter |
| Thread Engagement | 12 mm max |
Performance Features
- Measures vibration from 0.25 to 1.75 mm
- Works at temperatures from -62°F to +351°F
- 75Ω coaxial cable with FEP insulation
- Viton O-ring pressure seal
- Accuracy: ±0.06 mm
Setup Instructions
- Clean mounting hole surface
- Hand-tighten probe first
- Final torque: 5.1 N•m (45 in-lb)
- Set gap to 1.0 mm (40 mils)
- Keep cable bends >25.4 mm
Customer Questions
Q: What cable length comes with this probe?
A: 5.0 meters (16.4 feet) standard length.
Q: Can I use this with non-Bently systems?
A: Yes, works with any compatible monitoring system.
Q: Is pressure testing included?
A: No, contact us for special pressure testing.
Q: What shipping methods do you use?
A: FedEx, UPS, DHL with tracking.
Package Contents
- 3300 NSv probe unit
- 5m coaxial cable
- ClickLoc connector
