330903-00-05-05-12-05 Bently Nevada 3300 NSv Proximity Probe

Description

Bently Nevada 3300 NSv Proximity Probe: Precision Industrial Sensing

Description

New & original Bently Nevada 330903-00-05-05-12-05 proximity probe with factory sealing. Features enhanced chemical resistance and superior side-view performance vs. older models. Direct replacement for 3300 RAM probes. Includes 12-month warranty.

Technical Specifications

• Brand: Bently Nevada
• Full Model: 330903-00-05-05-12-05
• Range: 1.5 mm (60 mils)
• Accuracy: ±0.06 mm (±2.3 mils)
• Output: 7.87 V/mm (200 mV/mil)
• Temp Range: -52°C to +177°C
• Cable: 0.5m FEP coaxial
• Thread: M8X1 (12mm max engagement)

Installation Guide

Set gap to 1.0 mm (40 mils). Torque: 5.1 N•m max. Use shielded triad cable (max 305m). Maintain 25.4mm bend radius.

Compatibility

Fully interchangeable with 3300 RAM probes & cables. Superior to 3000-series 190 probes.

Certifications

Multiple agency approvals (suffix: -05)

Packaging & Warranty

Factory-sealed with original packing. 12-month warranty included.

Shipping

Ships globally via FedEx, UPS, DHL in 1-3 business days.

FAQ

Q: Minimum target size?
A: 8.9mm diameter (13mm recommended).

Q: Pressure rating?
A: Viton O-ring seal; contact for pressure testing.

Q: Cable options?
A: 0.5/1/5/7m lengths available.
