Description
Bently Nevada 3300 NSv Proximity Probe with Extended Cable
Product Overview
Factory-fresh 330903-00-05-10-02-00 proximity sensor featuring 1.0 meter cable length and M8X1 threading. Ideal for installations requiring extended reach. Full 12-month warranty included.
Complete Suffix Analysis
- → Base Model: 330903 (NSv Probe)
- → -00-: Zero unthreaded length
- → -05-: 50mm case length
- → -10-: 1.0 meter cable
- → -02-: Mini ClickLoc connector
- → -00: No agency approvals required
Detailed Technical Parameters
- Cable Resistance: 4.2Ω ±0.5Ω (1m length)
- Signal Linearity: ±0.06mm deviation
- Dynamic Response: 10kHz bandwidth
- Insulation Resistance: >100MΩ @500VDC
- Output Slope: 7.87 V/mm ±20%
- Material Compatibility: Resists oils, solvents, weak acids
Model Comparison
Current Configuration: 330903-00-05-10-02-00
– Cable: 1.0m standard
– Approvals: Not required
– Case: 50mm
Comparison Model: 330903-00-05-05-01-00
– Cable: 0.5m FluidLoc
– Approvals: Not required
– Case: 50mm
Comparison Model: 330903-00-05-05-11-00
– Cable: 0.5m FluidLoc
– Connector: With protector
– Case: 50mm
Installation Specifications
- Optimal sensing distance: 1.0mm from target
- Max cable tension: 15N (3.4 lbf)
- Thread engagement: 12mm maximum
- Bend radius: 25.4mm minimum
Performance Validation
Tested to 10 million operation cycles at 177°C. Maintains calibration within ±2% after thermal shock testing between -52°C and +177°C.
Maintenance & Support
Includes calibration certificate. Technical support available for integration with Bently Nevada 3500/3300 monitoring systems.
FAQ
Q: Advantages of 1.0m vs 0.5m cable?
A: Reduces extension cable needs in tight installations
Q: Suitable for underwater use?
A: Not recommended – Viton seal for differential pressure only
Q: Replacement for 3300 RAM probes?
A: Yes – fully compatible with existing mounts
Q: Chemical compatibility with chlorine?
A: Limited resistance – consult chemical compatibility chart
