Bentley Nevada 3300 NSv Protected Vibration Probe
Durable Machine Health Monitoring
Factory-new M8 vibration sensor with connector protector. Ideal for harsh environments where cables need extra protection. 12-month warranty included.
Product Code Explained
330903-00-05-50-01-00
│
├─ 330903 = M8 thread probe
├─ 00 = Smooth body (no threads)
├─ 05 = Compact 50mm case
├─ 50 = 5 meter cable
├─ 01 = ClickLoc with protector
└─ 00 = Standard approval
Essential Specifications
- • Resistance: 5.3Ω ±0.7Ω
- • Range: 0.25-1.75mm vibration
- • Sensitivity: 7.87V/mm ±20%
- • Response: 0-10,000 Hz
- • Cable: 5m FEP coaxial
Installation Guide
- 1. Torque: 5.1 N•m (45 in-lb)
- 2. Max thread: 12mm
- 3. Set gap: 1.0mm from target
- 4. Min target: 8.9mm diameter
- 5. Bend radius: >25.4mm
Technical FAQs
Q: What does “01” suffix mean?
A: Includes connector protector for extra safety
Q: Cable extension options?
A: Supports up to 305m with shielded triad cable
Q: Voltage output at 1mm gap?
A: Approximately -8 Vdc
Q: Suitable for washdown areas?
A: Yes, PPS tip resists water and chemicals
Q: Vibration accuracy?
A: ±0.06mm across measurement range
