Bentley Nevada 3300 NSv Compact Vibration Probe
Precision Shaft Monitoring Made Simple
New M8-thread vibration sensor for tight spaces. Measures machine health in pumps, motors and small turbines. Original factory packaging with warranty.
Part Number Breakdown
330903-00-05-50-02-00
└ 330903 = M8 thread probe
└ 00 = 0mm unthreaded length
└ 05 = 50mm case length
└ 50 = 5m cable
└ 02 = ClickLoc connector
└ 00 = No approvals needed
Key Measurements
- • Resistance: 5.3Ω ±0.7Ω
- • Range: Measures 0.25-1.75mm vibration
- • Accuracy: ±0.06mm deviation
- • Response: 0-10kHz frequency
- • Cable: 75Ω FEP coaxial (5m)
Installation Guide
- 1. Use 5.1 N•m torque (max 7.3 N•m)
- 2. Max thread: 12mm
- 3. Set gap: 1.0mm from target
- 4. Min target size: 8.9mm diameter
- 5. Cable bend: >25.4mm radius
Package Includes
- • 330903-00-05-50-02-00 probe
- • ClickLoc connector
- • Installation guide
• 12-month warranty
Shipping Options
- • FedEx International Priority
- • UPS Worldwide Express
- • DHL Express Worldwide
- • Tracked delivery in 2-5 days
Expert Answers
Q: Minimum target size?
A: 8.9mm diameter (13mm recommended)
Q: Cable length options?
A: 0.5m, 1m, 5m (this model), or 7m
Q: Voltage output range?
A: -1 to -13 Vdc (40 mil gap setting)
Q: Works with extension cables?
A: Yes, up to 305m with shielded triad cable
Q: Chemical resistance?
A: PPS tip resists oils, solvents and mild acids
