Description
330903-00-05-50-11-00: M8 Thread Vibration Probe with FluidLoc Cable
Bently Nevada’s compact probe features M8X1 threading and special FluidLoc cable. Perfect for tight spaces in motors and gearboxes.
SUFFIX BREAKDOWN
- Base: 330903 (M8 Thread Probe)
- 00: 0mm Unthreaded Section
- 05: 50mm Case Length
- 50: 5.0m Cable
- 11: ClickLoc + FluidLoc
- 00: No Approvals Needed
MEASUREMENT SPECS
- Linear Range: 1.5mm (60 mils)
- Gap Setting: 1.0mm (40 mils)
- Scale Factor: 7.87 V/mm
- Accuracy: ±0.06mm
- Target Size: Min 8.9mm diameter
CABLE PERFORMANCE
- 5m FluidLoc Cable
- Resistance: 5.3Ω ±0.7
- Max Field Wiring: 305m
- Bend Radius: 25.4mm
INSTALLATION NOTES
- Torque: Finger tight + 1/4 turn
- Max: 5.1 N•m (45 in•lb)
- Thread Engagement: Max 12mm
COMPATIBILITY
Works with all 3300 XL NSv systems. Replaces older 3300 RAM probes with better chemical resistance.
WHAT YOU GET
- 1x Probe (330903-00-05-50-11-00)
- Connector protector
- 12-month factory warranty
SHIPPING
Global delivery via FedEx/UPS/DHL. Ships same day.
FREQUENCY FACTS
- 0-10 kHz response range
- ±3 dB signal stability
- Detects cavitation at 5kHz+
COMMON QUESTIONS
Q: Minimum target size?
A: 8.9mm diameter flat surface
Q: Cable length options?
A: 0.5m, 1m, 5m, or 7m available
Q: Chemical resistance?
A: Better than older RAM probes
