330903-00-10-05-02-CN Bently Nevada Proximity Probe No Armor

Description

Bently Nevada 3300 NSv Proximity Probe (330903-00-10-05-02-CN)

New OEM vibration sensor with country-specific approvals for global compliance.

Suffix Configuration Tree

• 330903 – Base model (M8X1 thread)
• 00 – Unthreaded length: 0mm
• 10 – Case length: 100mm
• 05 – Cable: 0.5m standard
• 02 – Connector: ClickLoc
• CN – Country-specific approval

Detailed Technical Parameters

• Electrical Specs:
  • Center conductor resistance: 0.110Ω (0.5m)
  • Shield resistance: 0.033Ω (0.5m)
  • Capacitance: 35 pF (0.5m)
• Mechanical Specs:
  • Case material: 304 SST
  • Tip material: PPS polymer
  • Weight: 85g (with cable)
• Performance:
  • Response time: <0.1ms
  • Hysteresis: <0.5% FSO
  • Thermal drift: 0.05%/°C

Installation Specifications

• Mounting torque: 5.1 N•m (45 in-lb)
• Probe seating: Full thread engagement required
• Cable strain relief: 50N minimum
• Alignment tolerance: ±2° angular

Model Comparison

Certification Information

• CN-specific industrial compliance
• RoHS 3 compliant
• REACH SVHC < 0.1%

Shipping & Support

• Warranty: 12 months factory
• Packaging: ESD-protective casing
• Delivery: FedEx/UPS/DHL (2-5 days)
• Support: Technical documentation included

Expert FAQs

Q: Difference between standard and FluidLoc cables?
A: FluidLoc has enhanced chemical resistance for oil/gas applications

Q: How does case length affect installation?
A: Longer cases (100mm) require deeper mounting holes but provide better stability

Q: Country-specific approval implications?
A: Ensures compliance with local industrial regulations (e.g. China GB standards)

Q: Calibration requirements?
A: Recommend annual calibration for critical machinery

Q: Vibration limit for this probe?
A: 10g peak at 10kHz maximum
