330904-00-15-10-02-00 Bently Nevada 3300 NSv Probe With Armor

Description

Bently Nevada 3300 NSv Probe: Compact Vibration Monitoring

New factory-sealed sensor with 1-year warranty. Ships globally via FedEx/UPS/DHL. Perfect for tight spaces.

Part Number Configuration

• Complete ID: 330904-00-15-10-02-00
• Feature Breakdown:
  • 00: No unthreaded section
  • 15: 150mm extended case
  • 10: 1.0 meter cable
  • 02: Standard ClickLoc connector
  • 00: No safety certifications

Essential Specifications

• Cable Length: 1.0m (39 inches)
• Probe Resistance: 4.2Ω ±0.5Ω
• Accuracy: ±0.06mm deviation
• Response Rate: 10,000 samples/second
• Temp Range: -52°C to +177°C
• Min Target Size: 8.9mm diameter

Setup Instructions

• Position 1.0mm from target surface
• Tighten by hand plus 1/4 turn maximum
• Maintain 25.4mm cable bend radius
• Max thread depth: 12mm

Package Contents

• 3300 NSv Probe (1m cable)
• ClickLoc connector
• Installation reference card
• 12-month warranty proof

Technical Answers

• Q: Why 1m cable length?
  A: For installations where monitor is close to equipment
• Q: Resistance difference vs longer cables?
  A: Lower resistance (4.2Ω) due to shorter wire
• Q: Can I use in explosive areas?
  A: No – lacks safety certifications (suffix -00)
• Q: Suitable for medical devices?
  A: Yes – stainless steel construction meets hygiene needs
• Q: Weight of this probe?
  A: Approximately 85g with 1m cable

Need Dimensions?
Download Size Drawing
