Description
Bently Nevada 3300 NSv Long-Armor Probe – 330904-00-16-05-02-00
Quick Overview
Industrial-grade armored probe with 160mm extended stainless steel case for deep installations. Perfect for confined spaces where standard probes won’t reach.
Why Choose This Probe?
| Deep Reach 160mm armored case accesses tight machinery spots | Reliable Withstands extreme -52°C to +177°C temps |
| Easy Install Short 0.5m cable simplifies routing | Precise ±0.06mm accuracy in vibration readings |
Technical Specs
| Part Number | 330904-00-16-05-02-00 |
| Suffix Code | -00- = Zero unthreaded length -16- = 160mm armored body -05- = 0.5 meter cable -02- = Standard ClickLoc connector -00- = No special approvals |
| Key Measurements | Range: 0.25-1.75mm Accuracy: ±0.06mm Output: -1 to -13 Vdc |
| Durability | Armor: AISI 304 stainless steel Tip: Chemical-resistant PPS Bend radius: 25.4mm min |
Installation Made Simple
- Set gap to 1.0mm (40 mils)
- Max torque: 5 in•lb (0.56 N•m)
- Thread depth: ≤12mm
- Works with shafts ≥13mm diameter
Package & Support
| In Box | Armored probe, connector, docs |
| Warranty | 12 months factory coverage |
| Shipping | FedEx/UPS/DHL (2-5 days globally) |
Common Questions
Q: How deep can this probe install?
A: 160mm case reaches deeper than standard probes.
Q: Cable length options?
A: Also available in 1m/5m/7m versions.
Q: Chemical resistance?
A: PPS tip withstands harsh industrial fluids.
