Description
Bently Nevada 3300 NSv Long-Reach Vibration Probe
Factory-new 330904-08-10-50-12-05 with 5-meter cable and 12-month warranty. Designed for hard-to-reach machinery monitoring in extreme conditions.
Complete Part Number Breakdown
- 330904 – Core 3300 NSv Probe (M8X1 armored)
- 08 – 80mm unthreaded section
- 10 – 100mm total case length
- 50 – 5.0 meter cable length
- 12 – ClickLoc connector + FluidLoc cable
- 05 – Multiple agency approvals
Critical Performance Data
- Cable Resistance: 5.3Ω ±0.7Ω
- Frequency Range: 0-10,000 Hz
- Voltage Output: -1V to -13V DC
- Response Tolerance: ±3dB up to 10kHz
- Thread Engagement: 12mm max depth
- Cable Capacitance: 69.9 pF/meter
- Shield Resistance: 0.066 Ω/m
Setup Instructions
- Position 1.0mm from target surface
- Hand-tighten only – no tools needed
- Keep cable bends over 25.4mm radius
- Use shielded wiring up to 305 meters
Compliance Certifications
Multiple international approvals included
Package Contents
- 3300 NSv Probe (330904-08-10-50-12-05)
- Original factory packaging
- 12-month quality warranty
Global Delivery
FedEx, UPS, DHL express shipping available
Technical FAQ
Q: Maximum cable extension length?
A: Up to 305 meters with shielded triad cable
Q: Chemical resistance level?
A: Exceeds older 3300 RAM probe standards
Q: Pressure sealing capability?
A: Viton O-ring seals differential pressure
Q: Vibration tolerance limits?
A: Designed for high-vibration industrial environments
Q: Suitable for outdoor use?
A> Yes, -52°C to +177°C operating range
Get Installation Files
Download these resources for your 3300 NSv probe:
