Bently Nevada 3300 NSv Proximity Probe: Precision Industrial Sensing
New & original 3300 NSv Proximity Probe (Part: 330904-08-10-70-11-00) in factory packaging. Designed for harsh environments with chemical-resistant materials and 12-month warranty. Ships via FedEx, UPS, or DHL.
Full Suffix Breakdown: Model 330904-08-10-70-11-00
- Base Model: 330904 (3300 NSv Probe, M8X1 thread, armored)
- Unthreaded Length: -08 = 80 mm
- Case Length: -10 = 100 mm
- Cable Length: -70 = 7.0 meters
- Connector/Cable: -11 = Miniature ClickLoc + FluidLoc®
- Certification: -00 = Not required
Technical Specifications
| Brand | Bently Nevada |
| Linear Range | 0.25–1.75 mm (10–70 mils) |
| Sensitivity | 7.87 V/mm ±12.5%/-20% |
| Linearity (DSL) | ±0.06 mm (±2.3 mils) |
| Frequency Response | 0–10 kHz (±3 dB) |
| Probe Resistance | 5.9 Ω ±0.9 Ω (7.0m length) |
| Temp Range | -52°C to +177°C (-62°F to +351°F) |
| Cable Type | 75 Ω coaxial, FEP-insulated, stainless steel armor |
| Min. Bend Radius | 25.4 mm (1.0 in) |
Installation Guide
- Gap Setting: 1.0 mm (40 mils) from target
- Torque: Finger-tight (max 0.56 N•m / 5 in•lb)
- Thread Engagement: Max 12 mm for M8X1
- Use shielded triad cable (max 305m field wiring)
Compatibility & Interchangeability
Electrically and mechanically compatible with legacy 3300 RAM probes. Not compatible with 3000-series 190 probes due to superior side-view performance.
Diagnostics & Applications
- Targets: Shafts ≥13 mm diameter (axial vibration)
- Typical Use: Process compressors, turbines, pumps
- Diagnostic Capability: Detects unbalance, misalignment, bearing wear
Certifications & Packaging
- Agency Approval: Not required (suffix -00)
- Package Includes: Probe, connector protector, docs
- Warranty: 12 months
FAQ
- Q: Is this probe pressure-sealed?
A: Yes, Viton O-ring seals differential pressure (not factory-tested). - Q: Cable length options?
A: 0.5m, 1m, 5m, or 7m (this model: 7.0m). - Q: Minimum target size?
A: 8.9 mm diameter (13 mm recommended).
