330904-08-15-10-12-05 | 3300 NSv Probe Bently Nevada Buy Now

Description

Bently Nevada 3300 NSv Probe 330904-08-15-10-12-05 – 1m FluidLoc Cable

Configuration Details

• Full Part Number: 330904-08-15-10-12-05
• Option Breakdown:
  • → Base: 330904 (M8X1 armored probe)
  • → UL: -08 (80mm unthreaded)
  • → OCL: -15 (150mm case length)
  • → TL: -10 (1.0m cable)
  • → Conn: -12 (ClickLoc + FluidLoc)
  • → Cert: -05 (Multiple approvals)

Technical Highlights

• Electrical:
  • Resistance: 4.2Ω ±0.5Ω
  • Capacitance: 69.9 pF/m
  • Response: 0-10kHz (±3dB)
• Mechanical:
  • Case: AISI 304 stainless steel
  • Tip: PPS material
  • Bend radius: 25.4mm min
• Performance:
  • Range: 0.25-1.75mm
  • Sensitivity: 7.87 V/mm
  • Linearity: ±0.06mm

Installation Guide

• Gap setting: 1.0mm (40 mils)
• Torque: 5.1 N•m max
• Thread engagement: 12mm max
• Works with 3300 RAM systems

Shipping & Support

• 12-month warranty
• Global delivery: FedEx/UPS/DHL
• Temperature range: -52°C to +177°C
• Click to download installation manual

Expert Questions

• Q: FluidLoc cable benefits?
  A: Superior chemical/oil resistance
• Q: Approval certifications?
  A: Multiple global standards (option -05)
• Q: Minimum shaft size?
  A: 8.9mm diameter minimum
• Q: Pressure seal type?
  A: Viton O-ring (custom testing available)
• Q: Cable armor protection?
  A: Stainless steel armored jacket
