330905-05-10-05-02-05 – 3300 Nsv Bently Nevada Proximity Probe

Description

Product Overview

The Bently Nevada 330905-05-10-05-02-05 is a new industrial sensor with a 12-month warranty. Features M10X1 threading, 100 mm case length, and a 0.5-meter standard cable with ClickLoc connector. Built for -52°C to +177°C extreme conditions.

Key Specs for 330905-05-10-05-02-05

• Part Code: -05-10-05-02-05 = 50 mm unthreaded, 100 mm case, 0.5m cable, ClickLoc connector, multi-approved.
• Probe Resistance: 4.0Ω ±0.5Ω (0.5m cable).
• Field Wiring: Supports 305 meters (shielded triad cable).
• Compatible With: All 3300 RAM probe systems.

Performance

• Measure Range: 1.5 mm (0.25–1.75 mm from target).
• Output Signal: 7.87V/mm ±12.5%, ±0.06mm error.
• Fast Response: 0–10,000 Hz (no signal loss up to 305m).
• Small Shafts: Works on shafts ≥8.9 mm (best ≥13 mm).

Durability

• Materials: PPS tip, stainless steel case.
• Installation: Tighten to 7.5 N·m (max 22.6 N·m).
• Bend Safety: Min 25.4 mm radius.
• Pressure Seal: Viton O-ring (untested).

Support & Warranty

Includes 1-year factory warranty. Questions? Email sales@ubestplc.com

Document Download here: 3300 XL NSv Proximity Transducer System Datasheet
