Description
Industrial-Grade Long-Reach Vibration Probe
GE Bently Nevada 3300 NSv Proximity Probe (330908-00-36-70-02-05) features an extended 3.6-inch stainless steel case for deep mounting applications. With 7m cable and hazardous area certifications, it’s ideal for power generation and heavy machinery monitoring. Made in USA.
Complete Technical Specifications
Brand & Model: GE Bently Nevada 3300 NSv
Full Product Suffix: 330908-00-36-70-02-05
Suffix Breakdown:
- 00: 0″ unthreaded length
- 36: 3.6″ case length
- 70: 7.0m cable (23 feet)
- 02: ClickLoc connector
- 05: Multiple agency approvals
Electrical:
- Impedance: 75 Ω coaxial
- Resistance: 5.9 Ω ±0.9 (center to outer conductor)
Mechanical:
- Thread: 3/8-24 UNF
- Max thread engagement: 0.563 in
- Weight: 14-150g (0.5-5.3oz)
Environmental:
- Operating range: -52°C to +177°C (-62°F to +351°F)
- Seal material: Viton O-ring
- Minimum temp warning: -34°C (-30°F)
Model Comparison
| Feature | This Model (330908-00-36-70-02-05) | 330908-12-16-10-02-00 | 330908-12-18-10-02-05 |
|---|---|---|---|
| Case Length | 3.6 inches | 1.6 inches | 1.8 inches |
| Cable Length | 7.0 meters | 1.0 meter | 1.0 meter |
| Agency Approvals | Multiple (05) | None (00) | Multiple (05) |
| Unthreaded Length | 0 inch | 1.2 inches | 1.2 inches |
Installation Notes
Torque Requirements:
- Maximum: 33.9 N•m (300 in•lb)
- Recommended: 11.3 N•m (100 in•lb)
Critical: Maintain thread engagement under 0.563″. Avoid permanent exposure below -34°C to prevent seal failure.
Certifications & Compatibility
Carries multiple international safety approvals (ATEX/IECEx). Compatible with all 3300 NSv monitoring systems. 75Ω impedance matches industry-standard vibration analyzers.
Shipping & Support
Package includes: 1 vibration probe, specification sheet
Shipping: FedEx/UPS/DHL with tracking
Warranty: 12 months against defects
Technical FAQ
Q: Why choose 3.6″ case length?
A: Extra reach for installations behind thick mounting surfaces or protective guards.
Q: Difference between 00 and 36 suffix codes?
A: First number (00) = unthreaded length, second (36) = total case length.
Q: Is the Viton seal chemical-resistant?
A: Yes, resists oils and fuels but not ketones or acetates.
Q: Can I cut the cable to custom length?
A: No – cutting voids warranty. Choose standard lengths: 0.5m,1m,5m or 7m.
