Description
Bently Nevada 3300 NSv Compact Proximity Probe
Complete Specifications
- Full Model Code: 330909-00-28-05-01-00
- Case Length: 2.8 inches
- Unthreaded Length: 0.0 inches
- Cable Length: 0.5 meter (20 inches)
- Resistance Value: 4.0Ω ±0.5Ω
- Thread Type: 3/8-24 UNF
- Connector: ClickLoc with protector
Environmental Ratings
- Operating Temp: -52°C to +177°C
- Seal Safety Limit: -34°C (-30°F)
- Humidity Resistance: <3% ASF change at 93% RH
- Pressure Seal: Viton® O-ring design
Installation Details
- Max Thread Depth: 0.563 inches
- Safe Tightening:
- 100 in·lb for full threads
- 66 in·lb for first 3 threads
- Weight Range: 0.5-5.3 oz
Certifications
Agency Approval: 00 (Not Required)
Package Contents
- 1 x Armored probe with connector protector
- 12-month quality guarantee
- Worldwide shipping: FedEx, UPS, DHL
Technical FAQ
Q: Why use the connector protector?
A: Prevents damage during installation in tight spaces.
Q: What’s the unthreaded length?
A: 0.0 inches – fully threaded design.
Q: Minimum safe storage temperature?
A: -52°C, but avoid below -34°C for long periods.
Model Comparison
| Feature | This Model 330909-00-28-05-01-00 | 330909-00-60-10-02-00 | 330909-00-20-10-01-05 |
|---|---|---|---|
| Case Length | 2.8 in | 6.0 in | 2.0 in |
| Cable Length | 0.5 m | 1.0 m | 1.0 m |
| Connector | With protector | Without protector | With protector |
| Approvals | Not required | Not required | Multiple |
