Description
330909-00-28-10-01-00 3300 NSv Industrial Vibration Probe
U.S.-made stainless steel proximity sensor for machine health monitoring. Features armored threading and chemical-resistant tip.
Key Features
- Armored design: 3/8-24 UNF thread with protective casing
- Durable materials: AISI304 stainless steel body + PPS tip
- 1.0 meter FEP-insulated cable (75 Ω coaxial)
- ClickLoc connector with safety protector
- Wide temperature range: -52°C to +177°C
Technical Specifications
- Brand/Model: 3300 NSv Proximity Probe
- Full Code: 330909-00-28-10-01-00 (00 Unthreaded/28 Case Length/10 Cable Length/01 Connector/00 No Approval)
- Output Signal: Analog via 75 Ω coaxial
- Accuracy: 4.2 ± 0.5 Ω resistance at 1m
- Temperature Range: -52°C to +177°C (operating & storage)
- Weight: 14-150g (0.5-5.3oz)
- Pressure Seal: Viton O-ring (avoid sustained use below -34°C)
Installation Guide
- Max Torque: 33.9 N•m (300 in•lb)
- Recommended Torque: 11.3 N•m (100 in•lb)
- Thread Engagement: Max 0.563 inch
Package Includes
- Vibration probe unit
- ClickLoc connector with protector
- 12-month warranty
Shipping Options
FedEx | UPS | DHL – Global delivery available
Frequently Asked Questions
- Q: Maximum operating temperature?
A: +177°C (351°F) – avoid sustained cold below -34°C - Q: Pressure testing included?
A: No – seals differential pressure via O-ring - Q: Cable length options?
A: 0.5m, 1m, 5m, 7m (this model: 1.0m)
