Description
Bently Nevada Armored Vibration Probe with Cable Protection
Heavy-duty proximity sensor with armored cable and 6-inch body. Made in USA for tough industrial environments. Features connector protector and multiple safety certifications.
Product Highlights
| Part Number | 330909-00-60-05-01-05 |
| Special Feature | Armored Cable Protection |
| Case Length | 6.0 inches (long-reach design) |
| Cable Length | 0.5 meter (20 inches) |
Technical Specifications
- Armor Type: Flexible stainless steel with FEP jacket
- Thread Size: 3/8-24 UNF
- Case Material: AISI304 Stainless Steel
- Tip Material: Chemical-resistant PPS
- Temp Range: -52°C to +177°C (-62°F to +351°F)
- DC Resistance: 4.0Ω ± 0.5Ω
- Connector: ClickLoc with protector
- Max Torque: 33.9 N•m (300 in•lb)
Suffix Breakdown
- 00: 0.0 in unthreaded length
- 60: 6.0 in case length
- 05: 0.5 meter cable
- 01: ClickLoc connector with protector
- 05: Multiple agency approvals
Installation Guide
- Max thread engagement: 0.563 inch
- Recommended torque: 11.3 N•m (100 in•lb)
- First three threads max: 22.6 N•m (200 in•lb)
- Pressure seal: Viton O-ring (not factory tested)
Certifications
Multiple global approvals for hazardous environments
Shipping & Warranty
- 12-month manufacturer warranty
- Worldwide delivery: FedEx, UPS, DHL
- Armored protective packaging
Comparison to Similar Models
| Feature | This Model | Standard Probe |
|---|---|---|
| Cable Protection | Armored jacket | Standard FEP |
| Case Length | 6.0 inches | 3.6 inches |
| Connector | With protector | Basic ClickLoc |
| Approvals | Multiple global | Basic |
FAQ
Q: Why armored cable?
A: Protects against crushing, abrasion and chemicals
Q: When to use 6-inch length?
A: For deep installations in thick machinery walls
Q: Connector protector purpose?
A: Prevents damage during installation in tight spaces
Q: Alternative cable lengths?
A: Available in 1m, 5m or 7m armored versions
