330910-03-09-05-02-05 – Bently Nevada 3300 NSv Probe Hazardous Area

Description

🔹 Compact · rugged · 3300 NSv Proximity Probes

• Brand: Bently Nevada · model: 330910-03-09-05-02-05 · series: NSv Proximity Probes with M10×1 armor.
• New & original, factory sealed. 12‑month warranty included.
• Ideal for compressors, turbines, pumps. Enhanced chemical resistance vs 3300 RAM.
• Linear range 1.5 mm (60 mils), scale factor 7.87 V/mm (200 mV/mil).
• Multiple approvals (-05) – ready for hazardous locations.

📐 Part number tree · 330910-03-09-05-02-05

• 330910 = 3300 NSv probe, M10×1 thread, with stainless steel armor
  • -03 = unthreaded length: 30 mm
  • -09 = overall case length: 90 mm
  • -05 = total probe length: 0.5 m (20 in)
    • cable included, FEP insulated 75 Ω coaxial
  • -02 = connector: miniature coaxial ClickLoc, std cable
  • -05 = agency approvals: multiple (ATEX, IECEx, etc.)

⚙️ Core specifications · hierarchical

• Measurement performance
  • Linear range: 1.5 mm (60 mils) · 0.25 mm to 1.75 mm gap
  • Incremental scale factor (ISF): 7.87 V/mm ±12.5%/-20%
  • Deviation from straight line (DSL): < ±0.06 mm (±2.3 mils)
  • Frequency response: 0 – 10 kHz (+0/‑3 dB) with 305 m cable
• Electrical data
  • Probe dc resistance (0.5 m): 4.0 Ω ±0.5 (center to outer)
  • Extension cable: center 0.220 Ω/m · shield 0.066 Ω/m · capacitance 69.9 pF/m
  • Field wiring: 3‑conductor shielded triad, max 305 m to proximitor
  • Conductor size: 0.2 – 1.5 mm² (24 – 16 AWG) · ferrules 18 – 23 AWG
• Environmental & mechanical limits
  • Temperature: -52 °C to +177 °C (operating/storage)
  • Probe tip: PPS · case: AISI 304 SST · Viton O‑ring pressure seal
  • Min bend radius: 25.4 mm (1.0 in) even with armor
  • Torque: finger tight max 0.56 N·m · connector max 33.9 N·m
• Target / mounting
  • Min target diameter: 8.9 mm (0.35″) · recommended ≥13 mm (0.5″)
  • Thread engagement limit (M10×1): 0.563″ max
  • Recommended gap setting: 1.0 mm (40 mils)

🔧 Easy installation · practical tips

• Side‑view superior to 3000‑series 190 – gap at same distance.
• ClickLoc connector: fast, secure, no special tools.
• Field wiring up to 305 m – use shielded triad.
• Weight approx 14 g to 150 g (depending on length).
• Always observe torque values: finger tight for case, 11.3 N·m recommended for connector.

✅ Compatibility & certifications

• Fully interchangeable with 3300 RAM probes and extension cables.
• Works with 3300 XL NSv Proximity Probes Proximitor.
• Agency option -05: multiple approvals (ATEX, IECEx, CSA).
• Temperature classifications: EPL Ga/Gc T1 – T5, EPL Dc variants.
• Custom pressure test available on request (contact us).

📦 Delivery · warranty · logistics

• Factory‑sealed new unit, original Bently Nevada packing.
• 12‑month warranty from shipment date (parts & workmanship).
• Ship worldwide: FedEx, UPS, DHL – fast and insured.
• Included: probe with armor, ClickLoc connector, installation notice.
• Questions? sales@powergearx.com or WhatsApp +86 18030005825

📊 Field proven · diagnostic power

• Radial vibration, axial position, eccentricity on turbomachinery.
• High chemical resistance – ideal for sour gas, process compressors.
• Linear range captures shaft centerline changes, rub, misalignment.
• 0–10 kHz signal fidelity supports advanced diagnostics (FFT, enveloping).
• Plug‑and‑play with 3500/3300 monitoring systems.

❓ Expert FAQ · selection know‑how

• Q: How does the 12‑month warranty work – does it cover both probe and cable?
  A: Yes, the factory warranty covers the complete probe assembly including cable and connector. 12 months from delivery, no hidden exceptions.
• Q: Which shipping carriers do you use for urgent deliveries?
  A: We ship via FedEx, UPS, and DHL. Express service is available. Tracking provided same day.
• Q: I see -05 approval option – is this probe suitable for Zone 1 gas groups?
  A: Yes, -05 includes ATEX / IECEx for gas and dust. It meets IIA, IIB, H2, and temperature class T3/T4 depending on ambient. Refer to certificate.
• Q: My shaft is only 10 mm diameter – can I still use this 0.5 m probe?
  A: Possibly, but scale factor may shift. Reduce gap closer to 0.8 mm and perform a static calibration. Recommended min target is 13 mm.
• Q: What is the difference between -03‑09‑05 and the previous -14‑19‑10 version?
  A: The -03‑09‑05 has shorter unthreaded length (30 mm vs 140 mm) and shorter overall case (90 mm vs 190 mm). Total cable is 0.5 m instead of 1.0 m. Choose based on space constraints.
