Description
Bently Nevada 330980-51-05: Multi-Certified DIN-Rail Sensor
Global compliance meets compact design. This 5-meter NSv sensor carries multiple international approvals (suffix 05) and fits high-density control panels. SpringLoc terminals enable 15-second wiring – no tools required.
SUFFIX CODE EXPLAINED
- 51 = 5.0m system + DIN mount
- 05 = Multiple agency approvals:
- ATEX/IECEx Zone 2
- UKCA
- EAC (Eurasian)
- cCSAus (Canada/US)
PERFORMANCE SPECS
▶ Electrical
- Frequency Response: 0 to 12 kHz
- Signal Noise: <20 mV p-p
- Isolation: 500V RMS
▶ Mechanical
- Vibration Survival: 20G @ 10-2000 Hz
- Shock Resistance: 100G (11ms)
- Housing: A380 aluminum
MODEL COMPARISON
| Feature | 330980-51-05 (This Model) | 330980-70-05 | 330980-71-CN |
|---|---|---|---|
| Length | 5.0m | 7.0m | 7.0m |
| Approvals | Global (05) | Global (05) | Country (CN) |
| Use Case | Compact panels | Long-reach apps | Regional compliance |
INSTALLATION GUIDE
- Mount on 35mm DIN rail
- Connect probe to red terminal
- Apply -24Vdc (±10%)
- Set 1.27mm gap to target
- Verify output: -10Vdc @ 1mm gap
KIT CONTENTS
- 330980-51-05 Proximitor
- DIN rail clip set
- Terminal labels
Backed by 12-month warranty. Ships via FedEx, UPS, DHL with tracking.
FREQUENT QUESTIONS
Q: What approvals does “05” include?
A: ATEX, UKCA, EAC, cCSAus – certified for global hazardous locations.
Q: Can I use in Zone 0 areas?
A: No – rated for Zone 2/Division 2 only.
Q: Minimum order quantity?
A: Single unit available – ships same day.
Q: Calibration certificate included?
A> Yes – full traceable documentation provided.
