3500/45-05-00 Position Monitor | Bently Nevada

Description

Bently Nevada Position Monitoring System

A multi-functional position monitoring solution (Model Number:3500/45-05-00) designed for precision measurement of AC/DC LVDTs, proximity sensors, and rotary potentiometers in industrial applications.

Technical Specifications

• Brand: Bently Nevada
• Model: 3500/45-05-00
• Input Channels: 1-4 signals (LVDT/Proximity/RPT)
• Power Consumption: 8.5W typical (AC)
• Input Impedance:
  1 MΩ (DC LVDT) |
  10 kΩ (Proximity/RPT) |
  137 kΩ (AC LVDT)

Voltage Supply

• Proximity/RPT: -24 Vdc
• DC LVDT: +15 Vdc
• AC LVDT: 2.3Vrms @ 3.4 kHz
• Rotary Potentiometer: -12.38 Vdc

Physical Dimensions

• Monitor Module: 241.3×24.4×241.8mm | 0.91kg
• I/O Module: 241.3×24.4×99.1mm | 0.20kg

Ordering Details

• I/O Module Type: AC LVDT Position with Internal Terminations
• Agency Approval: None
• Recommended Spares:
  139554-01 (AC LVDT I/O Module) |
  176449-04 (Position Monitor)

System Advantages

• 4-channel flexibility for mixed sensor types
• Dual power modes (AC/DC) for field adaptability
• High-accuracy 1 MΩ impedance for DC LVDTs

Warranty: 2-year coverage on electronic components.

Contact: For configuration support or datasheets, email sales@ubestplc.com.
