Product Overview
The Bently Nevada 3500/77M-03-00 module monitors machinery pressure. It supports up to four pressure sensors. Front panel LEDs show system status clearly. This module protects critical industrial equipment.
Key Features
- Four-Channel Input: Works with 1-4 Bently Nevada pressure transducers
- Instant Status Display: LEDs indicate Signal OK and Bypass mode
- Integrated Power Supply: Provides +23V DC to each transducer
- Industrial Durability: Built for tough factory environments
- Easy Installation: Fits standard 3500 series frames
Technical Specifications
- Brand & Model: Bently Nevada 3500/77M-03-00
- Part Number: 176449-07
- Input Channels: 4 independent pressure inputs
- Transducer Power: +23.0V DC ±0.8V per channel
- Current Limit: 24.5 mA maximum per channel
- Power Usage: 7.8 watts at full load
- Measurement Range: Compatible with approved psia transducers
- Frequency Response: Optimized for machinery monitoring
- Operating Temperature: Standard industrial range
- Environmental Protection: High noise and vibration resistance
- Electrical Compatibility: Works with 3500 series monitoring systems
Setup & Maintenance
Install this module in a 3500 series rack. Wiring follows standard procedures. No special tools required. Status LEDs simplify daily checks. The modular design allows quick replacement.
Compatibility & Applications
The module works with Bently Nevada 3500 frames. Use it for turbine pressure monitoring. Ideal for compressor and pump protection. Perfect for power generation plants. Suitable for oil and gas facilities.
Certification & Package
- Certifications: Meets industrial EMC standards
- Package Contents: 3500/77M-03-00 module, documentation
- Warranty: 12-month manufacturer warranty
- Shipping: Available via FedEx, UPS, DHL worldwide
Frequently Asked Questions
What transducers work with this module?
Use only Bently Nevada approved pressure transducers. Other brands may cause measurement errors.
How do I check module health?
Watch the front panel LEDs. Green Signal OK light means proper operation.
Can I install this module myself?
We recommend qualified technicians. Proper installation ensures safety and accuracy.
What’s the main advantage from your experience?
The separate channel power prevents cross-talk. Each sensor gets clean, stable power.
How quickly can you ship?
We process orders within 24 hours. Express shipping takes 3-5 business days.
