Description
Introduction:
The 3625 Supervised Digital Output (SDO) Module is engineered for applications requiring precise and reliable output control, especially when outputs may remain in a single state for extended periods. These modules utilize a fault-tolerant quadruplicated output switch that ensures a single voted output signal is transmitted to the field termination. With built-in voltage and current loopback circuitry, SDO modules provide continuous online diagnostics, ensuring optimal performance and fault coverage.
Module Specifications:
Model Number: 3625
Nominal Voltage: 24 VDC
Type: TMR, Supervised/Non-Supervised DO
- Output Signals: 32, commoned
- Voltage Range: 16-32 VDC
- Maximum Voltage: 36 VDC
- Voltage Drop: < 2.8 VDC @ 1.7A (typical)
- Power Module Load: < 13 watts
- Current Ratings:
- 1.7A per point
- 7A surge per 10 ms (maximum)
- Minimum Required Load: 10 mA
- Load Leakage: 4 mA (maximum)
- Fuses (on Field Termination): N/A — self-protecting
- Point Isolation: 1,500 VDC
- Diagnostic Indicators:
- On or Off State: 1 per point
- Module Status: PASS, FAULT, ACTIVE
- Field Alarm: POWER, LOAD (1 per point)
Color Code: Dark blue
Weight: 4.7 to 6.0 lbs. (2.1 kg to 2.7 kg)
