Description
Bently Nevada 9200-03-02-02-00 Vertical Mount Vibration Sentinel
Factory-new vertical vibration monitor with 1-year protection. Global express shipping available.
Vertical Vibration Specialist
Engineered for 90° vertical mounting with side connector. Perfect for tight spaces where top access is limited.
Key Advantages
- 90° vertical mounting
- Side connector for tight spaces
- 1/4-28 UNF stud for secure attachment
- 4.5Hz low-frequency detection
Technical Highlights
- 20 mV/mm/s sensitivity
- -29°C to +121°C operation
- 25 mm/s velocity range
- 300g lightweight design
Model Comparison Guide
| Feature | 9200-03-02-02-00 | 9200-09-01-02-01 | 9200-01-01-01-00 |
|---|---|---|---|
| Mounting Angle | 90° Vertical | 45° Angled | 0° Horizontal |
| Connector | Side Mount | Top Mount | Top Mount |
| Frequency Range | 4.5Hz-100Hz | 10Hz-100Hz | 4.5Hz-100Hz |
| Stud Size | 1/4-28 UNF | M10×1 | 1/4-20 UNC |
Industrial Problem Solver
Vertical Pumps:
Monitors vibration in tight pump pits where side access is only option.
Tower Structures:
Ideal for vertical vibration monitoring in communication towers.
Installation Tips
- Use proper torque (8-10 Nm) on 1/4-28 UNF stud
- Ensure vertical orientation (±2.5° tolerance)
- Leave clearance for side connector access
Why Choose This Model?
- Space-saving side connector design
- Optimized for vertical surfaces
- Superior low-frequency response (4.5Hz)
- Secure UNF threaded connection
