Description
Bently Nevada 990 Vibration Transmitter: Smart Factory Solution
CN-Certified Precision
● Measures 0-8 mils/200μm vibrations
● DIN clip+screw dual mounting (model 990-08-50-03-CN)
● Full China industrial approvals
Complete Specifications for 990-08-50-03-CN
Model Code Breakdown:
08=0-8 mils |
50=5m system |
03=DIN clips+screws |
CN=China certified
???? Accuracy: ±1.5% full range
???? Response: 5Hz-6,000Hz
???? Weight: 0.9lbs/0.43kg
???? Cable: 3m max BNC connection
???? Temp: -40°C to +85°C
Industrial Applications
• Robotic assembly line monitoring
• High-speed train bogie systems
• Solar panel manufacturing robots
• Smart warehouse conveyor belts
Quick Installation
1. Clip onto 35mm DIN rail
2. Add screws for extra security
3. Set 0.5-1.75mm probe gap
4. Connect 28V power & test
Global Support
✓ 12-month full warranty
✓ Ships via FedEx/DHL/UPS
✓ COO certificate available
Technical Advantages
• Fault response in 100μs
• Works with 9.5mm+ metal targets
• 1000Ω max loop resistance
• IP54 dust/moisture protection
Operator FAQ
Q: Approved in Shenzhen?
A: Full CN compliance
Q: Vibration limits?
A: 0-8 mils range
Q: Manual languages?
A: CN/EN versions included
