Description
Bently Nevada 990-10-50-03-CN: DIN Rail-Mounted Transmitter with China Certifications
???? Top Features
???????? CN Certified
Meets China’s industrial safety standards
Meets China’s industrial safety standards
⚡ Quick-Install
Tool-free DIN rail mounting (clips included)
Tool-free DIN rail mounting (clips included)
???? High Accuracy
±1.5% full-scale 4-20mA output
±1.5% full-scale 4-20mA output
???? Rugged Design
5m cable system, 0.43kg lightweight
5m cable system, 0.43kg lightweight
???? Key Specifications for 990-10-50-03-CN
- Model Decoder: 10=10 mils | 50=5m cable | 03=DIN mount | CN=China approval
- Range: 0-250μm (0-10 mils pp)
- Response: 5Hz-6kHz (±3dB)
- Power: 12-35VDC @28V typical
- Fault Response: <3.6mA output within 100μs
???? What You Get
- Transmitter unit
- DIN rail clips & screws
- CN compliance papers
- 12-month warranty
???? Comparison Spotlight
990-10-50-03-01
Same range but CSA Div 2 certified instead of CN
990-10-50-02-CN
Bulkhead mount version with CN approval
???? Pro Tips
- Use 3300 NSv probes for best performance
- Maintain 0.5-1.75mm probe-to-target gap
- Max 3m BNC cable length for signal integrity
???? Global Support
Shipped via DHL/FedEx/UPS – China-optimized logistics
❓ Quick Answers
Does this work with 24V systems?
Yes! Compatible with 12-35VDC power inputs.
