Description

Bently Nevada 990-04-50-03-00: Compact Vibration Monitor

Precision for Critical Machinery

Bently Nevada’s 990-04-50-03-00 delivers ±1.5% accuracy for 0-4 mils vibration monitoring. Built for 5m cable runs and DIN-rail mounting. Ideal for pumps, motors, or fans in non-hazardous areas.

Key Specs

• Brand: Bently Nevada
• Range: 0-4 mils (0-100 μm)
• Cable: 5m/16.4ft (max 3m BNC)
• Response: <100 µs fault detection
• Power: 12-35V DC (low energy)

Easy Setup

Mounts with DIN clips + screws. Works with 3300 NSv probes. Probe gap: 0.5-1.75mm (20-55 mils). No certifications needed.

Durable Performance

• Handles -35°C to +85°C
• 5Hz-6kHz frequency range
• 23mA current limiting

Warranty & Shipping

• 12-month warranty
• Ships via FedEx/UPS/DHL
• Optional Certificate of Origin

Typical Uses

• HVAC system motor monitoring
• Conveyor belt bearing checks
• Industrial fan balancing

FAQ

Q: Hazardous area approved?
A: No – designed for standard zones.

Q: Minimum target size?
A: 9.5mm (0.375″) diameter.

Q: Self-diagnostic features?
A: Yes – Not OK signal alerts in <100µs.
