Allen-Bradley 1746-IO12DC: 6 Input/6 Output DC Combo Module
Get the powerful Allen-Bradley 1746-IO12DC for your SLC 500 system. This combo module has six 24V DC inputs and six relay outputs. It fits in one slot to save space and cost. Perfect for controlling sensors, small motors, and lights.
Complete Technical Data
- Brand: Allen-Bradley
- Model: 1746-IO12DC
- Series: SLC 500
- Module Type: Digital I/O Combination
- Input Channels: 6
- Input Voltage: 10-30 VDC
- Output Channels: 6 Relay (N.O.)
- Output Rating: 2.0A max
- AC Switching: 120V AC @ 1.5A
- DC Switching: 24V DC @ 1.2A
- On Delay: 35ms
- Off Delay: 45ms
- Backplane Current: 80mA @ 5V DC
- Work Temperature: 0 to 60°C (32 to 140°F)
What’s In The Box?
- One (1) 1746-IO12DC Module
12 Month Warranty
We offer a 12-month warranty. It covers any problems from material or workmanship defects.
We Ship Fast
We ship orders quickly using FedEx, UPS, and DHL.
Download The Manual
Get the complete manual for wiring and setup info:
- Find wiring diagrams.
- See detailed specifications.
- Learn installation best practices.
- Download The Manual Here
Frequently Asked Questions
- Q1: What devices can I connect to the DC inputs?
- A1: You can connect proximity sensors, push buttons, and other 24V DC field devices.
- Q2: Can the relay outputs control a 120V AC light bulb?
- A2: Yes. Each output can switch up to 1.5A at 120V AC, perfect for lights and small loads.
- Q3: What is the minimum input voltage the module will detect?
- A3: The input will recognize a signal as ‘ON’ at 10V DC or higher.
- Q4: How much current does the module use from the backplane?
- A4: It uses a maximum of 80 milliamps from the 5V DC backplane power.
- Q5: Are the outputs fused?
- A5: No, the outputs are not internally fused. You should add external fuses to protect your wiring.
