Allen-Bradley 1756-OF8IK ControlLogix Analog Output Module

Description

Allen-Bradley ControlLogix Isolated Analog Output Module

Experience precision control with the Allen-Bradley 1756-OF8IK. This versatile module delivers eight isolated analog outputs for accurate process control. It supports both current and voltage signals with high resolution.

Technical Specifications

Brand: Allen-Bradley
Model: 1756-OF8IK
Series: ControlLogix
Type: Isolated Analog Output Module
Channels: 8 isolated outputs
Current Output: 0-20mA, 4-20mA
Voltage Output: -10 to +10V
Resolution: 16 bits
Output Impedance: 46 Ohms
Load Capacity: 0-1000Ω (current mode)
Protection: ±30V overvoltage protection
Power Dissipation: 6.5W max
Backplane Current: 200mA @ 5.1V DC
Isolation: Channel-to-channel and channel-to-backplane
Terminal Blocks: 1756-TBNH, 1756-TBSH
Scan Time: 1ms
Wire Size: 22-14 AWG

Package & Support

• One 1756-OF8IK analog output module
• 12-month reliability warranty
• Global shipping via FedEx, UPS, DHL

Resources & Documentation

• Installation instructions
• Wiring guidance
• Configuration examples
• Download full technical manual here
