Allen-Bradley 1768-ENBT: Ethernet/IP Communication Module
This advanced communication module connects your CompactLogix system to Ethernet networks. The 1768-ENBT enables fast data exchange with various industrial devices. Perfect for modern automation systems requiring network connectivity.
- EtherNet/IP connectivity for industrial networks
- Fast 10/100 Mbps communication speed
- Connects to HMIs, drives, and other devices
- Works with CompactLogix L43 and L45 controllers
Technical Specifications
| Brand | Allen-Bradley |
| Model | 1768-ENBT |
| Series | CompactLogix |
| Module Type | EtherNet/IP Communication |
| Network Protocol | EtherNet/IP |
| Data Speed | 10/100 Mbps (auto-negotiating) |
| Ethernet Port | 1 RJ45 connector |
| Maximum Connections | 64 CIP, 32 TCP/IP |
| Backplane Current | 834 mA @ 5.2V DC |
| Power Consumption | 4.34 Watts |
| Cable Type | Category 5/6 Ethernet |
| Compatible Controllers | 1768-L43, 1768-L45 |
| Maximum Modules (L43) | 2 modules |
| Maximum Modules (L45) | 4 modules |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Vibration Rating | 5g @ 10-500 Hz |
| Shock Rating | 30g operating |
Warranty & Shipping
We provide a 12-month warranty. Ships worldwide via FedEx, UPS, or DHL.
Frequently Asked Questions
- What devices can connect to this module?
It connects to drives, HMIs, SCADA systems, motor starters, and other Ethernet/IP devices. - What Ethernet speed does it support?
It supports both 10 Mbps and 100 Mbps speeds with auto-negotiation. - How many connections can it handle?
It supports up to 64 CIP connections and 32 TCP/IP connections. - Which controllers work with this module?
It works with CompactLogix 1768-L43 and 1768-L45 controllers. - What cables should I use?
Use standard Category 5 or Category 6 Ethernet cables with RJ45 connectors.
