Allen-Bradley 1769-PB4 DC Power Supply
Get reliable DC power for your CompactLogix system. The Allen-Bradley 1769-PB4 delivers stable power for industrial controls. This 1769-PB4 module is perfect for 24V DC applications.
Key Benefits
- High Power Output: 4A at 5V DC and 2A at 24V DC
- Wide Input Range: Works from 19.2V to 31.2V DC
- Expandable System: Powers up to 16 I/O modules
- Rugged Design: Built for tough industrial environments
Technical Specifications
- Brand: Allen-Bradley
- Model: 1769-PB4
- Input Voltage: 19.2-31.2V DC (Nominal 24V DC)
- Output 1: 5V DC @ 4.0 Amps
- Output 2: 24V DC @ 2.0 Amps
- Power Consumption: 100 VA
- Inrush Current: Max 30A
- Fuse Rating: 6.3A Fast-Acting
- Isolation Voltage: 75V Continuous
- Operating Temperature: 0°C to 60°C
- Weight: 1.39 lb (0.63 kg)
- Dimensions: 4.65″ x 2.76″ x 3.43″
Installation Guide
Mount the 1769-PB4 on DIN rail or panel. Keep 50mm space for cooling. Use proper grounding. Follow wire size guidelines.
Compatible Products
This power supply works with many 1769 modules. For complete systems, consider:
1769-ADN DeviceNet Scanner
1769-AENTR Ethernet/IP Adapter
FAQ
- What is the maximum altitude for operation? Up to 2000 meters (6562 feet).
- Can it handle vibration? Yes, it operates in 5g vibration environments.
- What wire size should I use? Use 14-22 AWG copper wire.
- Is this suitable for harsh environments? Yes, it has industrial-grade protection.
- What is the isolation voltage rating? 75V continuous isolation.
