Allen-Bradley 1783-US5T Stratix 2000 Managed Ethernet Switch

Description

Product Overview

• Allen-Bradley 1783-US5T is a compact managed Ethernet switch.
• Belongs to the Stratix 2000 Series by Rockwell Automation.
• Designed for reliable industrial automation networks.
• Ideal for PLC, HMI, and control systems.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1783-US5T
• Product type: Managed Ethernet switch
• Ports: 5 × RJ45 copper
• Speed: 10/100 Mbps
• Fiber ports: None
• SFP slots: None

Power & Electrical

• Nominal voltage: 24 VAC/VDC
• Input range: 12–48 VDC, 18–30 VAC
• Frequency: 50/60 Hz
• Power consumption: 3.4 W max
• Inrush current: 1.85 A

Environmental Ratings

• Operating temperature: -10°C to +60°C
• Max ambient temperature: 60°C
• Shock resistance: 15 g
• Industrial noise immunity

Mechanical & Installation

• Mounting: DIN rail
• Enclosure: Open-style
• Dimensions: 114.5 × 76.8 × 29.6 mm
• Connector type: RJ45

Diagnostics & Maintenance

• LED indicators for link and activity
• Easy fault detection
• Low maintenance design

Compatibility

• Compatible with Allen-Bradley PLC systems
• Supports EtherNet/IP devices
• Uses Cat5 and Cat5e cables

Typical Applications

• Factory automation
• Machine control panels
• Industrial Ethernet networks

Package & Shipping

• Includes 1783-US5T switch unit
• Standard industrial packaging
• Shipping via FedEx, UPS, or DHL

Warranty

• 12-month warranty
• Technical support available

FAQ

• Can this switch use DC power?
• Yes, it supports wide-range DC input.
• Is it suitable for harsh environments?
• Yes, when installed in a protected enclosure.
• How do I choose this model?
• Select it for compact Fast Ethernet control networks.
