Description
Allen-Bradley 1784-U2DN USB to DeviceNet Communication Cable
Bridge your computer to DeviceNet networks with this versatile interface cable. The 1784-U2DN enables easy configuration and monitoring of industrial automation systems.
Technical Specifications
| Manufacturer | Allen-Bradley/Rockwell Automation |
| Model Number | 1784-U2DN |
| Cable Type | USB to DeviceNet |
| Length | 0.61 meters (2 feet) |
| Data Rates | 125, 250, 500 kbps |
| Voltage Requirements | 5V DC (USB), 24V DC (DeviceNet) |
| Current Draw | 75 mA @ 24V DC |
| Enclosure Rating | IP20 |
| Operating Temperature | 0°C to 55°C |
| Connector Type | 5-pin Phoenix male |
| Power Consumption | 0.5 Watts |
| Weight | 0.23 lbs (104 grams) |
| Warranty | 12 Months |
Frequently Asked Questions
- What data rates does this cable support?
It supports three data rates: 125, 250, and 500 kbps for flexible network configuration. - How do I set the node address?
Use the built-in rotary switch on the cable housing to select the desired node address. - What do the LED indicators show?
Blue and red LEDs display network activity, module status, and self-test results. - Is this cable waterproof?
No, it has an IP20 rating which means it’s not waterproof or dustproof. - What power does this cable require?
It uses 5V from USB and 24V from DeviceNet for operation.
