Description
Allen-Bradley 22B-D4P0F104 PowerFlex 40 AC Drive – 2HP, 480V, Flange Mount
The PowerFlex 40 (22B-D4P0F104) is a compact, high-performance AC drive designed for precise motor control. With 2HP, 480V, and 4.0A output, it’s ideal for industrial automation. Features RS-485 communication and keypad input for easy operation. Download the full manual here.
Technical Data
- Brand: Allen-Bradley (Rockwell Automation)
- Model: 22B-D4P0F104 (PowerFlex 40 Series)
- Voltage: 480V AC, 3-Phase
- Current: 4.0A
- Horsepower: 2HP
- Enclosure: Flange Mount (IP20, NEMA/UL Open)
- Communication: RS-485
- Input Type: Keypad Control
- Operating Temp: -10°C to 50°C (with clearance)
- Storage Temp: -40°C to 85°C
Installation Guide
- Mount vertically on a flat surface.
- Allow 4.7 inches clearance above/below.
- Keep 1-inch spacing between drives (recommended).
- Avoid moisture, dust, and direct sunlight.
- Wait 3+ minutes after power-off for capacitor discharge.
Compatibility & Safety
- Works with 3-phase motors.
- Contains high-voltage capacitors (handle with care).
- MOVs are ground-referenced.
Shipping & Warranty
- Packaging: Drive, keypad, manual.
- Shipping: FedEx, UPS, DHL (global).
- 12-month warranty included.
Need more details? Download the manual here.
