Allen-Bradley 1769-CRL3 Expansion Cable
Expand your CompactLogix system easily. The Allen-Bradley 1769-CRL3 connects I/O banks. This 1769-CRL3 cable is 1 meter long for flexible setups.
Key Features
- Right to Left Connection: Links module banks together
- 1 Meter Length: Perfect for most cabinet layouts
- Durable Design: Built for industrial environments
- Easy Installation: Simple plug-and-play setup
Technical Specifications
- Brand: Allen-Bradley
- Model: 1769-CRL3
- Product Line: CompactLogix
- Cable Type: Right-to-Left Expansion
- Length: 1 meter (3.28 feet)
- Operating Temperature: 0°C to 60°C
- Isolation Voltage: 30V Continuous
- Backplane Current: 1.4A at 24V
- Power Consumption: 33.6 Watts
- Weight: 300 grams
- Storage Temperature: -40°C to 85°C
Installation Guide
Connect the 1769-CRL3 between I/O banks. Ensure proper alignment. Keep away from heat sources. Check connections are secure.
Compatible Products
Works with all 1769 CompactLogix modules. Popular choices include:
1769-IA16 16-Point AC Input
1769-IA8I 8-Point AC Input
FAQ
- How many cables can I use? Maximum 2 cables per system.
- What is the maximum distance? Allows up to 3 I/O banks.
- Is installation difficult? No, simple connection between modules.
- What environments does it work in? Standard industrial conditions.
- Can I use longer cables? This is the standard 1-meter length.
