Allen-Bradley 1762-OA8: 8-Point AC Output Module
Product Description
The Allen-Bradley 1762-OA8 is a solid-state AC output module. It is designed for use with MicroLogix controllers. This module has 8 triac outputs. It controls AC loads like valves, contactors, and motor starters.
Technical Data
| Brand | Allen-Bradley |
| Model | 1762-OA8 |
| Series | MicroLogix 1762 |
| Module Type | 8-Point AC Output |
| Output Type | Triac, Solid-State |
| Operating Voltage | 85 to 265V AC |
| Frequency | 47 – 63 Hz |
| Input Power | 100 – 240V AC |
| On-State Current | 0.5 A per point |
| Voltage Drop | 1.5V max |
| Heat Dissipation | 2.9 W |
| Operating Temperature | 32 to 131°F (0 to 55°C) |
| Storage Temperature | -40 to 185°F (-40 to 85°C) |
| Dimensions (HxWxD) | 3.54 x 1.59 x 3.43 inches |
| Weight | 0.5 lbs |
Installation Guide
Mount the module on a proper metal panel. Ensure a good ground connection. Follow Allen-Bradley’s wiring rules. Clear all metal fragments before applying power. The finger-safe cover must be in place during wiring. Note: The cover cannot be reattached after wiring.
Compatibility
This module works with:
- MicroLogix 1100 controllers
- MicroLogix 1200 controllers
- MicroLogix 1400 controllers
Certification & Standards
This product meets these standards:
- NEMA ICS 2-230
- EN50081-2 Class A
- IEC1000-4-2
- IEC1000-4-3
Package Includes
- One 1762-OA8 Output Module
- Documentation
Warranty & Shipping
We offer a 12-month warranty. We ship worldwide via FedEx, UPS, and DHL.
