Armored & FluidLock Proximity Probe: Bently Nevada 330104-05-17-10-11-05

Description

Armored Proximity Probe for Maximum Physical Protection

This top-tier Bently Nevada 3300 XL 8mm Probe includes a protective armored section. It combines armor, FluidLoc leak-proofing, and hazardous area approvals. It is the ultimate choice for extreme environments with high risk of impact, fluids, and explosions.

Full Model Specification Decoded

The detailed product code 330104-05-17-10-11-05 reveals all features:

• Base Model & Armor:
  • 330104 = 3300 XL 8 mm Probe, M10 x 1 thread, with armor.
• Precise Dimensions:
  • 05 | Unthreaded Length (Armored): 50 mm.
  • 17 | Overall Case Length: 170 mm.
  • 10 | Total Cable Length: 1.0 meter.
• Premium Connection & Safety:
  • 11 | Connector: ClickLoc with protector & FluidLoc cable.
  • 05 | Agency Approvals: CSA, ATEX, IECEx (Full Certifications).

Technical Specifications & Build

• Measurement Accuracy:
  • Linear Range: 2.0 mm.
  • Probe Resistance (1.0m): 7.59 ± 0.5 Ω.
  • Standard Sensitivity: 7.87 V/mm.
• Ultra-Robust Construction:
  • Case: 303/304 Stainless Steel with armored section.
  • Tip: High-strength PPS Plastic.
  • Seals: Viton O-ring (pressure) + FluidLoc cable (leak).
• Environmental Limits:
  • Temperature: -52°C to +177°C (operating).
  • Thread Engagement (M10x1): Do not exceed 15 mm.

Dual Protection: Armor & FluidLoc

• Armored Section: Protects the probe cable where it exits the housing from crushing, abrasion, and physical impact.
• FluidLoc Cable: Prevents internal oil migration along the cable, protecting electrical connections.
• Hazardous Area Certified: Rated for Zone 0, 1, 2 with appropriate intrinsic safety (ia) or non-incendive (nA, ec) installations.

Target Use Cases

This probe is designed for the toughest applications: heavy machinery with vibration, areas with flying debris, oily/wet conditions, and classified hazardous areas like refineries or offshore platforms.

Complete Package & Support

• One armored 3300 XL 8mm probe with FluidLoc cable and connector guard.
• Full certification documentation.
• 12-month product warranty.
• Express international shipping via FedEx, UPS, or DHL.

Expert FAQs for Tough Applications

What is the “armored” section, and where is it?

The armor is a rigid metal sheath over the first 50mm of the cable (specified by “-05”). It protects the cable where it is most vulnerable, right at the probe case exit.

When is an armored probe necessary?

Use an armored probe when the cable is exposed to potential impact, crushing, abrasion from insulation, or heavy vibration. It is critical in pulp/paper, mining, or heavy steel industries.

Does the armor affect installation?

Slightly. Ensure the mounting hole or gland is large enough for the armored cable diameter. The armored section must be fully supported and clamped securely.

Can I get this configuration without FluidLoc?

Yes. The “-11” specifies both connector protector and FluidLoc. For armor without FluidLoc, you would choose a different “Connector and Cable-Type Option” code (e.g., -01 or -02). Contact us to configure.

What is the lead time for this specialized probe?

This is a premium configuration. While often in stock, please confirm availability. We use FedEx/DHL/UPS for fast delivery once your order is ready.

Need to specify a probe for a severe service application? Get engineering support on WhatsApp: +86 158 8020 0923.
