ATEX Certified 330103-00-18-05-02-05 Probe | Bently Nevada 3300 XL 8mm Sensor

Description

Product Summary: Certified Short-Cable Probe

This Bently Nevada 3300 XL 8mm Probe combines safety with a compact design. It carries full hazardous area certifications. The 0.5 meter cable is ideal for tight spaces. Its M10x1 thread is the global metric standard.

Complete Product Configuration

Part number 330103-00-18-05-02-05 details your exact probe build.

• Base Model: 330103 (8mm, M10x1, No Armor)
• Feature Map:

  • 00 – Unthreaded Length: 0 mm (Fully threaded)

  • 18 – Case Length: 180 mm (7.1 inches)

  • 05 – Cable Length: 0.5 meter (1.6 feet)

  • 02 – Connector: Standard ClickLoc

  • 05 – Approvals: CSA, ATEX, IECEx

Technical Specifications

• Measurement Performance

  ▪ Linear Range: 2.0 mm (80 mils)

  ▪ Sensitivity: 7.87 V/mm

  ▪ Probe Resistance: 7.45 Ω ±0.50 Ω (for 0.5m)

• Mechanical Details

  ▪ Thread: M10 x 1.0

  ▪ Max Engagement: 15 mm

  ▪ Torque (Full): 11.2 N•m recommended

  ▪ Torque (First 3 threads): 7.5 N•m recommended

• Certifications & Ratings

  ▪ Safety: ATEX, IECEx, CSA (Option 05)

  ▪ Temperature: -52°C to +177°C standard

  ▪ Humidity: <3% change at 93% RH

  ▪ Hazardous Zones: Zone 0/1/2 with proper barriers

Product Advantages

• Hazardous Area Ready: Pre-certified for explosive atmospheres.
• Compact Installation: Short 0.5m cable reduces clutter.
• Long 180mm Case: Fits deep mounting applications.
• Metric Thread Standard: M10x1 for worldwide compatibility.
• No Extra Armor: Cost-effective for protected environments.

Installation Instructions

• Thread fully into M10x1 hole. Do not exceed 15mm depth.
• Use correct torque: 11.2 N•m for full thread, 7.5 N•m for first 3 threads.
• Set gap to 1.27mm (50 mils) from target shaft.
• Connect short cable to extension lead in junction box.
• Follow hazardous area wiring codes for certified installation.

Common Applications

• Petrochemical and pharmaceutical plants (hazardous zones).
• Motor and pump vibration monitoring with metric fittings.
• Applications requiring ATEX certification in Europe.
• Machinery with deep bearing housings (180mm case).

Expert FAQs

What does “00” unthreaded length mean?

It means the probe case is fully threaded from the tip. There is no smooth section. This is useful for maximum thread engagement in deep holes.

Why are there two different torque specifications?

Use 7.5 N•m if only the first 3 threads are engaged (shallow hole). Use 11.2 N•m if the probe is fully threaded into a deeper hole. This prevents damage.

Can I use this 0.5m probe in a standard (non-hazardous) area?

Yes. The certifications add safety but do not limit use. This probe works perfectly in any industrial setting. For non-certified needs, see other 3300 NSv Probes.

What is the advantage of the 180mm case length?

The long case (180mm/7.1″) allows the probe tip to reach through thick machine housings. It positions the sensor correctly for measurement on deep-set bearings.

How do I maintain the pressure seal during installation?

Do not exceed the recommended torque. Ensure the threads are clean. The Viton® O-ring will seal properly when torqued correctly. Never test the seal with air or liquid pressure.

Purchase & Support Information

• What’s Included: One certified Bently Nevada 330103-00-18-05-02-05 probe.
• Warranty Coverage: 12-month manufacturer warranty against defects.
• Shipping Methods: Fast global delivery via FedEx, UPS, and DHL available.
• Technical Help: Reach our experts on WhatsApp: +86 158 8020 0923.
