ATEX Certified Bently Nevada 330104-19-25-10-11-05 Probe | Hazardous Area 3300 XL Sensor

Description

Product Description: Certified Safe Industrial Probe

This Bently Nevada 3300 XL 8mm Probe is a top-rated sensor. It has full safety approvals for hazardous areas. The M10x1 metric thread suits global machinery. Its armored body and FluidLoc cable provide maximum protection.

Product Configuration Details

Part number 330104-19-25-10-11-05 specifies every feature.

• Product Base: 330104 – 3300 XL 8mm Probe, M10x1 thread, with armor
• Configuration Tree:
  • ➤ Option 19: Unthreaded Length = 190 mm
  • ➤ Option 25: Overall Case Length = 250 mm
  • ➤ Option 10: Cable Length = 1.0 meter
  • ➤ Option 11: Connector = ClickLoc with protector & FluidLoc cable
  • ➤ Option 05: Approvals = CSA, ATEX, IECEx

Key Technical Specifications

• Measurement & Electrical
  • ▸ Linear Range: 2.0 mm (80 mils)
  • ▸ Recommended Gap: 1.27 mm (50 mils) for -9 Vdc
  • ▸ Probe Resistance (1.0m): 7.59 Ω ±0.50 Ω
  • ▸ Field Wiring: Max 305m with shielded cable
• Mechanical & Physical
  • ▸ Thread: M10 x 1.0 metric
  • ▸ Case Material: Armored Stainless Steel (303/304)
  • ▸ Tip Material: PPS Plastic
  • ▸ Max Thread Engagement: 15 mm
  • ▸ Torque: Max 33.9 N•m | Recommended 11.2 N•m
• Safety & Environment
  • ▸ Safety Approvals: CSA, ATEX, IECEx (Option 05)
  • ▸ Temperature Range: -52°C to +177°C standard
  • ▸ Pressure Seal: Viton® O-ring
  • ▸ Cable: FluidLoc option prevents fluid ingress

Main Product Advantages

• Hazardous Area Certified: Approved for use in explosive atmospheres.
• FluidLock Protection: Special cable stops oil and liquid leaks.
• Armored Durability: Extra metal armor protects the probe body.
• Global Metric Standard: M10x1 thread fits most international equipment.
• Easy Connection: ClickLoc connector with protector for secure link.

Installation Guide

• Use M10x1 mounting hole. Do not exceed 15mm thread engagement.
• Apply recommended 11.2 N•m torque. Do not over-tighten.
• Set probe tip gap to about 1.27mm from the target shaft.
• Connect the FluidLoc cable securely to the extension cable.
• Follow all safety rules for hazardous area installation.

Application Areas

• Oil & Gas platforms and refineries (hazardous zones).
• Chemical and petrochemical plants.
• Mining and milling equipment needing metric threads.
• Any area requiring ATEX/IECEx certified sensors.

Professional FAQs

What does “FluidLoc cable” mean?

FluidLoc is a special cable design. It blocks oil and other liquids from traveling inside the cable. This keeps fluids from leaking out of your machine at the connector.

What is the difference between this and standard 3300 XL probes?

This model 330104-19-25-10-11-05 has three key extras: 1) Armor casing, 2) FluidLoc cable, 3) Full ATEX/IECEx/CSA certifications for hazardous locations.

Can I use this probe in a Zone 1 area?

Yes. With the proper intrinsically safe barrier (per drawing 141092), this probe is certified for Class I, Zone 0 and Zone 1 hazardous areas. Always check your system certification.

Why is the torque specification important?

Proper torque (11.2 N•m) ensures a good seal without damaging the probe. Over-torquing can crush the O-ring and break the pressure seal.

How do I know if I need the armor option?

Choose armor if the probe may be hit by tools, debris, or during maintenance. It adds extra physical protection. For standard environments, non-armored probes like some 3300 NSv Probes may be sufficient.

Ordering & Service Information

• Package Includes: One certified probe ready for installation.
• Quality Warranty: Backed by a 12-month manufacturer warranty.
• Global Shipping: We dispatch via FedEx, UPS, or DHL express services.
• Need Help? Contact our technical sales team on WhatsApp.
