Bently Nevada 133300-01 Power Input Module PIM Low Voltage DC

Description

Product Identity

• Brand: Bently Nevada
• Model: 133300-01
• Series: 3500 System
• Module Type: Low Voltage DC Power Input Module
• Also known as a PIM module.
• Designed for stable rack power delivery.

Product Purpose

• Supplies reliable DC power to monitoring racks.
• Protects the system during voltage faults.
• Ensures continuous operation of critical modules.
• Suitable for single or dual supply setups.

Input Power Characteristics

• Input Voltage: 20 to 30 Vdc
• Nominal Voltage: 24 Vdc
• Under-voltage: No damage to supply or module.
• Over-voltage: Internal fuse opens safely.
• Inrush Current: Controlled at startup.

Output & Load Capability

• Maximum Current Draw: 10.0 A
• Supports full rack load.
• Stable output under dynamic demand.
• Low ripple for sensitive electronics.

Environmental Performance

• Operating Temperature: −30°C to +65°C
• Storage Temperature: −40°C to +85°C
• Humidity: Up to 95 percent, non-condensing
• Designed for industrial cabinets.
• Performs well in harsh plant conditions.

Mechanical Details

• Height: 120.7 mm
• Width: 25.4 mm
• Depth: 114.3 mm
• Weight: Approx. 0.34 kg
• Slim design saves rack space.

Safety & Compliance

• CE marked for industrial use.
• Meets EMC emission requirements.
• Resistant to surge and fast transients.
• Designed to EN 61010-1 safety standards.

Hazardous Area Approval

• CSA and NRTL certified.
• Approved for Class I Division 2.
• Groups A, B, C, and D supported.
• Suitable for oil and gas locations.

Ordering & Configuration Options

• Top slot or bottom slot installation.
• Single or redundant power layouts.
• Optional CSA agency approval.

Included Items

• One new 133300-01 Power Input Module.
• Factory-installed protection fuse.
• Standard industrial packaging.

Recommended Spare Parts

• Replacement fuse part number 01720045.
• Easy field replacement.

Key Advantages

• High current capacity.
• Strong electrical protection.
• Simple installation.
• Long service life.
• Trusted industrial design.

Warranty & Delivery

• Warranty: 12 months.
• Shipping: FedEx available.
• Shipping: UPS available.
• Shipping: DHL available.

Professional FAQ

• Can this module support redundant power?
• Yes. It works in dual supply configurations.
• What happens during over-voltage?
• The internal fuse opens to protect the system.
• Is this module suitable for hot climates?
• Yes. It operates up to 65°C.
• How do I choose top or bottom slot?
• Select based on rack layout and wiring access.
• Is this module recommended for critical assets?
• Yes. It is designed for continuous operation.
