Description
Product Overview
- The Bently Nevada 135799-01 is a display interface module for the 3500 system.
- It shows live system data in a clear visual form.
- The module supports local and remote display use.
- It improves operator awareness and response speed.
- Designed for continuous industrial operation.
Main Functions
- Displays system and alarm event lists.
- Shows real-time channel and monitor values.
- Reads data from relay and speed modules.
- Works with Keyphasor and tachometer inputs.
- Uses a fast internal rack network.
Core Technical Parameters
- Brand: Bently Nevada
- Model: 135799-01
- Series: 3500 Machinery Protection System
- Module Type: System Display Interface Module
- Data Update Rate: High-speed rack communication
Electrical Performance
- Max Power: 15.5 W with display unit
- -01 Display Power: 5.6 W
- -02 Display Power: 12.0 W
- Low heat output supports long service life.
Status & Diagnostics
- OK LED: Shows normal operation
- TX/RX LED: Shows data exchange activity
- Supports fast fault identification.
- Helps reduce downtime during alarms.
Environmental Endurance
- Operating Range: -30°C to +65°C
- Storage Range: -40°C to +85°C
- Humidity: Up to 95%, non-condensing
- Stable under harsh plant conditions.
Mechanical Details
- Size: 241.3 × 24.4 × 241.8 mm
- Weight: 0.82 kg
- Fits standard 3500 rack slots.
Key Selling Points
- Clear visual access to system health.
- Fast response to alarm conditions.
- No extra software needed for display.
- Designed by a trusted OEM brand.
- Long-term spare support available.
Installation & Use
- Slides directly into the 3500 rack.
- No field calibration required.
- Connects automatically to the rack network.
- Easy replacement during maintenance.
Typical Applications
- Central control rooms
- Turbine and compressor monitoring
- Critical rotating machinery
- Oil, gas, and power plants
Warranty & Shipping
- Warranty: 12 months
- Courier Options: FedEx, UPS, DHL
- Secure export packaging included.
FAQ
- Is this module required for basic system operation?
- No. It enhances visibility but is not mandatory.
- Can it display historical alarm data?
- Yes. It shows stored system event lists.
- Which display version should I select?
- Choose based on screen size and power needs.
- Is it suitable for unmanned sites?
- Yes. It supports remote status review.
- Does it affect rack performance?
- No. It only reads data from the network.
