Product Introduction
This is a brand new, original Bently Nevada 3300 series proximity probe. The specific part number is 146055-90-02-00. It is engineered for reverse mount installations to monitor critical machine vibration and position. The sensor features a resilient ceramic-capped tip and comes with a 9-meter integrated cable. Your unit is supplied as new in the original, unopened factory packaging.
Part Number Breakdown
- 146055 – Base Model: 3/8-24 UNF Thread Reverse Mount Probe
- -90 – Cable Length: 9.0 Meters Total
- -02 – Connection: Miniature ClickLoc Coaxial Connector, Standard Cable
- -00 – Approvals: Standard Version, No Special Agency Marks Required
- -02 – Connection: Miniature ClickLoc Coaxial Connector, Standard Cable
- -90 – Cable Length: 9.0 Meters Total
Detailed Technical Specifications
- Brand & Series: Bently Nevada 3300 Series
- Full Part Number: 146055-90-02-00
- Probe Function: Vibration and Position Measurement
- Mounting Style: Reverse (Back Mount)
- Thread Specification: 3/8-24 UNF
- Total Cable Length: 9.0 m (29.5 ft)
- Connector: Miniature ClickLoc (Coaxial)
- Probe Tip Material: Alumina Ceramic (Al2O3)
- Probe Body Material: AISI 304 Stainless Steel
- Nominal DC Resistance (9m): 9.87 Ω ± 0.90 Ω
- Linear Measurement Range: 1.52 mm (60 mils)
- System Sensitivity (Scale Factor): 7.87 V/mm (200 mV/mil) ±6.5%
- Output Range (Linear): Approx. -4 Vdc to -16 Vdc
- Recommended Target Material: AISI 4140 Steel
- Cable Impedance: 75 Ohm Coaxial
- Cable Insulation: FEP (Fluorinated Ethylene Propylene)
- Operating/Storage Temperature: -51°C to +177°C (-60°F to +351°F)
- Pressure Seal Rating: 34 Bar (500 psi) with Nitrogen
- Frequency Response: 0 to 10,000 Hz
- Maximum Thread Engagement: 14.3 mm (0.563 inches)
