Bently Nevada | 200151-20-02-02 Accelerometer Interface Standard Cable

Description

Bently Nevada 200151-20-02-02: Industrial Accelerometer Cable

Product Overview

Precision 2.0-meter accelerometer cable with IP67-rated connectors on both ends. Features nylon coupling nuts and flexible PVC jacket for vibration monitoring systems. Operating range: -20°C to +100°C.

Technical Specifications

• Brand: Bently Nevada
• Full Model: 200151-20-02-02
• Suffix Breakdown:
  • 20: 2.0 meter length
  • 02: Blue non-armored cable
  • 02: Nylon coupling nut
• Key Parameters:
  • Min. bend radius: 63.5 mm (2.5 in)
  • Conductors: 4×22 AWG with braided shield
  • Shield coverage: >85%
  • Material temp range: -55°C to +121°C
• Sealing: IP67 rating with DC4 moisture protection
• Cure Time: 24 hours (thermal shock protection)

Installation Notes

Critical: Avoid flexing below -20°C to prevent damage.

Maintain 63.5mm bend radius during routing.

Environmental Ratings

• Operating temp: -20°C to +100°C
• Material survival temp: -55°C to +121°C
• Thermal shock resistant

Package Contents

• 1× 2.0m Accelerometer Cable
• Nylon coupling nuts (both ends)
• Warranty: 12 months

Shipping Options

Global delivery via FedEx, UPS, DHL with tracking.

Frequently Asked Questions

Q: Can this cable handle extreme cold?
A: Yes (-55°C survival), but do not flex below -20°C.

Q: What does “02” suffix mean for nuts?
A: Nylon coupling nuts – corrosion resistant and lightweight.

Q: Moisture protection level?
A: IP67 rating + DC4 compound = waterproof connectors.

Q: Minimum bend radius?
A: 63.5mm (2.5″) – critical for installation.

DC4 compound requires 24hr cure time for full moisture protection.
